G99 High Efficiency 70 kW AC DC Converter RS485 Wall Mounted 460*190*800mm

G99 High Efficiency 70 kW AC DC Converter RS485 Wall Mounted 460*190*800mm
G99 High Efficiency 70 kW AC DC Converter RS485 Wall Mounted 460*190*800mm

Large Image :  G99 High Efficiency 70 kW AC DC Converter RS485 Wall Mounted 460*190*800mm

Product Details:
Place of Origin: CHINA
Brand Name: SINY
Certification: CE,G99
Model Number: MASI-70KW1
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: Exwork: 5,000~9,000 USD
Packaging Details: Carton
Delivery Time: 45 Work days
Payment Terms: T/T,
Supply Ability: 200 Per month
Detailed Product Description
Power: 70kW Efficiency: ≥98.2%
Standby Power Consumption: <120W Installation: Wall Mounting
Operating Temperature: -25℃ ~ +55℃(Power Derating Above +45℃) Protection Level: IP20
Size (W*H*D): 460*190*800mm Relative Humidity: 0~95%,No Condensation
Certification: G99/CE/CQC Communication Mode: RS485、CAN、LAN、REPO
Noise: <68dB Weight: 45kg
Display: Yes
High Light:

G99 High Efficiency AC DC Converte


High Efficiency AC DC Converter RS485


G99 AC DC Bidirectional Converter

70kW AC DC Bidirectional Converter Grid-connected Type for Micro Grid Energy Storage System



  • Wiith its own monitoring system, touch screen can be external, can be convenient to build a small energy storage system.
  • DC voltage design:600V~900V
  • Adaptable to a variety of grid voltages: AC380V/400V/415V.
  • Three-level design,low harmonics.
  • Small volume, less occupied space and convenient installation.
  • Charge/discharge conversion less than 20ms.
  • Convenient multi-device parallel network: Multi-branch high-power energy storage system can be formed by multiple PCS in parallel.
  • The 3U standard rack design can be perfectly combined with the lithium battery cabinet to form a distributed energy storage cabinet.
  • High power density, small size, two people can carry the installation by hand.
  • Three level design, low harmonics, good power quality.
  • Perfect matching of power battery echelon utilization application scenarios

Product specification










DC side parametersVoltage rangeDC600V~DC900V
Rated power



Maximum current



Number of DC channels









AC grid-connection parametersGrid type



Rated power



Rated voltage



Rated current



Voltage range-15%~+15%
Rated frequency



Frequency rangeRated frequency±3Hz
Power factor



Output harmonic≤3%
EnvironmentWorking temperature-25℃~55℃(Derating when temperature is above 45 °C)
Storage temperature-40℃~70℃(No battery)
Relative humidity0%RH~95%RH,No condensation
Working altitudeWhen the temperature is 45 °C, derating is not required for 2000m. Derating ranges from 2000m to 4000m


Communications and Management

Communication interfaceRS485,CAN,LAN
Communication protocolCAN,ModBus TCP,ModBus RTU
Installation Wall type
Display Yes
Highest efficiency







Class A




Isolation methodNo isolation
Protection grade



Cooling wayAir cooling, intelligent fan speed control











All performance and parameters shall be subject to the latest confirmation of our technical department
